Description
- Управление 3 контакторами.
- Setting an individual schedule for each contactor.
- Possibility of connecting several meters to one controller via network synchronization.
- Setting threshold levels to identify failed luminaires and unauthorized connections.
- Collection of data from meters via RS-485 interface.
- Built-in memory for autonomous operation of the controller according to a schedule in case of loss of the GSM signal.
- Built-in battery with the ability to operate autonomously for up to 60 minutes.
- Remote device firmware update.
- Automatic reboot when frozen.
- Connecting door opening sensors and fire alarms.
- Встроенные энергонезависимые часы реального времени.
.
Structurally, the module is made in a plastic case with protection rating IP67. The plastic of the module is resistant to UV radiation, temperature changes from -45 to +70°C.
The controller is a complete device that can be installed in an existing control cabinet or supplied as part of new equipment.
Specifications
Design
| Body material | Plastic |
|---|---|
| Overall dimensions | 145×90×55 |
| Device weight, g | 350 |
| Installation options | Fastening with fasteners |
Interface
| Type | RS-485 |
|---|---|
| Data transfer rate, baud | 1200~ 115 200 |
| Maximum length of communication line, m | 1000 |
| Data transfer protocol | Modbus |
| Insulation voltage, V | 2500 |
Modifications
| Modifications | DC100 | DC200.T3.MGE | |
|---|---|---|---|
 |  |
Inputs
| Number of discrete inputs, pcs. | 12 | 8 |
|---|---|---|
| Discrete input type | Contact sensor (requires external voltage source 12..24 V) | Contact sensor (requires external voltage source 12..24 V) |
Outputs
| Number of discrete outputs, pcs. | 4 | 3 |
|---|---|---|
| Discrete Output Types | Simistor with physical state memory (controlled by a bistable relay) | T0 — monostable relay T1 — open-source transistor (outgoing current control) T2 — thyristor T3 — thyristor with physical state memory (controlled by bistable relay)» |
Communication interfaces
| GSM | ||
|---|---|---|
| Standards | GSM 2G (GPRS), 4G (LTE), NB-IoT | GSM 2G (GPRS), 4G (LTE), NB-IoT |
| Supported protocols | NTP, FTP, FTPS, MQTT | NTP, FTP, FTPS, MQTT |
| RS-485 | ||
| Quantity, pcs. | 2 | 2 |
| Supported protocols | · Modbus-RTU · Protocols of various heat meters, flow meters, electricity meters, weather stations, air monitoring stations, temperature sensors, road surface sensors» | · Modbus-RTU · Protocols of various heat meters, flow meters, electricity meters, weather stations, air monitoring stations, temperature sensors, road surface sensors» |
| RS-485 exchange rate | 4800…115200 бит/с | 4800…115200 бит/с |
| Ethernet | ||
| Standards | 1 × 10/100 Мбит/c (RJ45) | |
| Supported protocols | NTP, FTP, FTPS, MQTT, Modbus-TCP, OPC UA | |
| Built-in UPS | ||
| Battery life, not less than, min. | 60 | 60 |
| Battery type | LifePo4, 18650, replaceable | LifePo4, 18650, replaceable |
Design
| Body material | Plastic | Plastic |
|---|---|---|
| Overall dimensions, mm | 145×90×55 | 160×90×55 |
| Degree of protection | IP54/63 | IP20 |
| Device weight, g | 350 | 250 |
| Installation options | на монтажную плату / на стену | на DIN-рейку |
| terms of Use | ||
| Temperature, °C | from -40 to +70 | from -40 to +70 |
| Relative humidity of air (without condensation), % | 90 | 90 |
| Nutrition | ||
| Power supply type | AC | AC |
| Supply voltage | 230V | 230V |
| Power consumption | до 10 Вт | до 10 Вт |
| Indication | ||
| LED indicators | Power availability GSM network signal level RS-485 interface exchange Battery charge | Power availability GSM network signal level RS-485 interface exchange Battery charge |
| LCD display | Optionally installed is a 32-character liquid crystal display (16 columns, 2 lines) with buttons for interaction with the controller menu |
Additional information
| Watchdog timer | available | available |
|---|---|---|
| Availability of a GNSS receiver with support for satellite systems | GPS/GLONASS | GPS/GLONASS |
| GSM modem antenna type | SMA | SMA |
| Remote firmware update | available | available |
| Server interaction protocol | MQTT | MQTT |
| Built-in real time clock | available | available |
| Limits of the basic absolute error of the clock in the absence of external synchronization, s/day | ±3 | ±3 |
| Built-in galvanically isolated power supply for discrete inputs | On separate terminals with a common ground with the inputs. Voltage 15 V | On separate terminals with a common ground with the inputs. Voltage 15 V |
| Completeness | ||
| Module of | 1 pc. | 1 pc. |
| Passport / Warranty card | 1 copy. | 1 copy. |
| Quick Start Guide | 1 copy. | 1 copy. |
