Description
The DigiCity Solar Tracker controller allows you to send a control signal to a connected device (servo/stepper motor) to change the position of the installed solar panel relative to the sun.
The DigiCity switch is software and hardware compatible with devices from other manufacturers and can be integrated into third-party systems.
Specifications
Общие параметры
| Overall dimensions, mm | 240 х 160 х 90 |
|---|---|
| Body material | Plastic |
| Climate performance, °C | from -40 to +70 |
| Supply voltage, V | IP65 |
| Built-in battery | Type 18650 |
| UPS Functions | Communication module for alarm only |
| Mode of transportation | Individually packaged |
Connection
| Communication interfaces | GSM (2G, 4G), LoRa |
|---|---|
| Built-in navigator | GPS, Glonass |
| GSM network registration | GPRS, LTE |
| Registration in the LoRaWAN network | ABP |
| GSM data exchange protocols | Proprietary on top of MQTT |
| LoRa Data Exchange Protocols | Proprietary using the LoRaWAN network |
| Support for remote software updates | GSM only |
| The LoRa antenna | Inside the case, passive |
Drive Parameters
| Engine type | Collector 's |
|---|---|
| Output voltage of the source | 12 Volts |
| Engine power | Up to 100 Watts |
| Protection of the control circuit | From overheating, overvoltage, low voltage, Overcurrent and short circuit |
